Programmable Digital Timer Switch


Programmable Digital Timer Switch

Specifications

Operating Voltage 130V to 280V
Box Type Powder Coated Box, Compact size Wall mounting, Temper proof and maintenance free.
Indication LED Indication status for MAINS & GENERATOR On
Technology Microcontroller based technology with Pre-Program interlocking to prevent short circuit.
Warranty 1 Year warranty against manufacturing defects
Supply voltage DC 12V, 24V, AC110-260V Freq–50Hz

Digital Time Switches are used where electrical equipment must be periodically switched on and off for pre-programmed daily or weekly times. Digital time switches available with only 5 pin timer. The 5 pin model connection is an AC 220 is just like a switch. It can be used for switching to any application individually or with group of appliances.

Features :

  • Digital programmable Daily, weekly timer basis.
  • Upto 16 programs daily
  • Inbuilt rechargeable V80H battery for memory backup means no issue of replacing battery, Battery charge last for at least 1-2 months without charge. i.e. Without AC supply connectivity.
  • Led power indicator, LCD on screen displays for on and off switching status.
  • Contact – single pole - single throw, Contact capacity-16 Amp, 240 VAC.
  • Running accuracy ± 1 second / day at 20°, Minimum time setting - 1 minute.
  • It can be used for street lights, motors, T.V., AC etc.
